node-red-contrib-shadow-check 1.0.1

A Node-RED node for checking if the sun shines into a window

npm install node-red-contrib-shadow-check

node-red-contrib-shadow-check

A Node-RED node that checks whether the sun currently shines into a configured window.

The node combines a window's dimensions, azimuth, inset and roof overhang settings with sun position input. It can be used to decide whether blinds or roller shutters should be lowered.

Installation

This node can be installed by searching for node-red-contrib-shadow-check in the Palette or running the following command in your Node-RED user directory – typically ~/.node-red.

$ npm install node-red-contrib-shadow-check

Usage

Input

The node expects sun position data on msg.payload:

{
  "azimuth": 180,
  "altitude": 35,
  "sunInSky": true
}

azimuth and altitude are degrees. sunInSky is optional and defaults to true. If sunInSky is false, the output payload is false.

Output

The node preserves the incoming message and sets:

• msg.payload: true if the sun shines into the configured window, otherwise false
• msg.topic: the configured topic, defaulting to sunInWindow

Development

npm ci --ignore-scripts
npm run lint
npm run typecheck
npm test
npm run build

Release versioning is managed with Changesets:

npm run changeset
