@fa_yoshinobu/node-red-contrib-plc-comm-slmp 0.2.1

Node-RED nodes for Mitsubishi PLC communication over SLMP binary 3E/4E frames.

npm install @fa_yoshinobu/node-red-contrib-plc-comm-slmp

Node-RED SLMP Nodes for Mitsubishi PLCs

Node-RED nodes for Mitsubishi PLC communication over SLMP binary 3E/4E frames.

This package uses the same named-device foundation as the SLMP libraries, extended here with Node-RED-friendly count and string forms:

• D100
• D100,10
• D200:F
• D200:F,4
• D300:L
• D50.3
• M1000
• M1000,8
• D100:STR,10
• DSTR100,10

Quick start

1. Install the package into your Node-RED user directory and restart Node-RED.
2. Add one slmp-connection config node and set host, port, transport, PLC series, and frame type.
3. Add slmp-read for the first smoke test, using a safe address such as D300, D300,4, or DSTR320,10.
4. When read works, add slmp-write and use known-safe test devices before moving to production addresses.

If you are working from this repository, import one of the ready-to-run flows under examples/flows first. The safest first choices are:

• slmp-basic-read-write.json for plain TCP scalar read/write
• slmp-array-string.json for ,count and string access
• slmp-device-matrix.json for one-by-one high-level coverage across the matrix catalog
• slmp-udp-read-write.json for UDP validation

Release information

• package name: @fa_yoshinobu/node-red-contrib-plc-comm-slmp
• package version: 0.2.1
• npm package: https://www.npmjs.com/package/@fa_yoshinobu/node-red-contrib-plc-comm-slmp
• Node-RED requirement: >=3.0.0
• Node.js requirement: >=18
• changelog: https://github.com/fa-yoshinobu/node-red-contrib-plc-comm-slmp/blob/main/CHANGELOG.md

Install from npm:

cd ~/.node-red
npm install @fa_yoshinobu/node-red-contrib-plc-comm-slmp

Install from this repository:

cd ~/.node-red
npm install /path/to/node-red-contrib-plc-comm-slmp

Legacy note:

• the original unscoped [email protected] remains on npm, but new releases move to the scoped package name above

Documentation

• User Guide
• Example Flows
• Future Device Support
• Maintainer Notes
• Validation Reports Directory
• Documentation Index

Current scope

• Binary 3E and 4E frames
• TCP and UDP transport
• Reusable slmp-connection config node
• slmp-read node powered by readNamed
• slmp-write node powered by writeNamed
• typed source selection for literal / msg / flow / global / env
• per-request routing via msg.target or configured route sources
• read output selection for object / array / single value
• metadata emission selection for msg.slmp: full / minimal / off
• configurable error handling with throw / msg.error / second output
• connection control via connect / disconnect / reinitialize messages
• editor-side validation for connection ranges, literal addresses, literal updates, and route JSON
• importable example flow under examples/flows/
• Local tests for codec and high-level helpers

Set frame type and PLC series explicitly for each connection.

Validated PLC models:

• FX5UC-32MT/D
• Q06UDVCPU
• R08CPU

Supported devices

Supported bit devices:

• SM, X, Y, M, L, F, V, B
• TS, TC, STS, STC
• CS, CC
• SB, DX, DY

Supported word devices:

• SD, D, W
• TN, LTN, STN, LSTN
• CN, LCN
• SW
• Z
• R, ZR, RD

Address notes:

• X, Y, B, W, SB, SW, DX, and DY use hexadecimal device numbers
• most other devices use decimal numbers
• word devices support .bit, for example D50.3
• count and string forms work on supported devices, for example D300,10, M1000,8, and DSTR320,10
• LTN, LSTN, and LCN default to 32-bit current-value access in the high-level nodes
• future device support candidates such as LTS, LTC, LSTS, LSTC, LCS, LCC, LZ, G, and HG are tracked in the Future Device Support list

Nodes

slmp-connection

Holds the transport and SLMP profile settings:

• host / port
• transport: tcp or udp
• timeout in milliseconds
• PLC series: ql or iqr
• frame type: 3e or 4e
• target routing fields

slmp-read

Reads one or more addresses and writes the result to msg.payload.

Configured addresses can be overridden by:

• msg.addresses as an array or string
• msg.payload as an array or string

Configured source modes:

• literal editor text
• msg
• flow
• global
• env

Examples:

D100
D100,10
D200:F
D200:F,4
D50.3
M1000
M1000,8
D100:STR,10
DSTR100,10

Notes:

• ,count returns an array for numeric and direct-bit reads
• :STR,<length> reads or writes a UTF-8 byte string packed two bytes per word
• DSTR100,10 is accepted as a compatibility alias for D100:STR,10
• LTN, LSTN, and LCN use high-level 32-bit current values by default
• when you send multiple addresses as a string, newline-separated input is the clearest form
• per-request routing can be supplied as msg.target, msg.slmp.target, or a configured route source
• metadata mode can keep full msg.slmp, emit only target plus itemCount, or leave msg.slmp unchanged
• read errors can throw, attach to msg.error, or go to a second output
• output can be object, array, or single value when one address is requested
• send msg.connect, msg.disconnect, or msg.reinitialize as true, or use msg.topic, to control the shared connection

slmp-write

Writes one or more addresses.

Preferred dynamic input:

{
  "D100": 42,
  "D100,3": [10, 11, 12],
  "D200:F": 3.14,
  "D200:F,2": [1.25, -2.5],
  "D50.3": true,
  "D100:STR,10": "HELLO"
}

Accepted sources:

• msg.updates
• msg.payload
• msg.address + optional msg.dtype + msg.value
• static JSON or address=value lines in the editor
• configured msg / flow / global / env sources

Write errors can throw, attach to msg.error, or go to a second output. Send msg.connect, msg.disconnect, or msg.reinitialize to control the shared connection from the write node too. Route overrides use the same target object shape as reads. Metadata mode can keep full msg.slmp, emit only target plus itemCount, or leave msg.slmp unchanged.

Route overrides

Use a target object when one request needs a different route than the shared connection default:

{
  "addresses": ["D300,4", "DSTR320,10"],
  "target": {
    "network": 0,
    "station": 255,
    "moduleIO": "03FF",
    "multidrop": 0
  }
}

The editor validates connection ranges, literal address lists, literal update payloads, and literal route JSON before save.

Example flows

Read:

{
  "addresses": ["D100", "D100,3", "D200:F", "D200:F,2", "D50.3", "D100:STR,10"]
}

Write:

{
  "payload": {
    "D100": 42,
    "D100,3": [10, 11, 12],
    "D50.3": true,
    "D100:STR,10": "HELLO"
  }
}

Import one of the ready-to-run flows under examples/flows:

• slmp-demo.json: combined demo
• slmp-basic-read-write.json: scalar, float, and bit read/write over TCP
• slmp-array-string.json: array and string read/write over TCP
• slmp-control-error.json: control messages, msg source, and second-output errors
• slmp-device-matrix.json: one-by-one high-level read, write, and readback across the matrix catalog with completed-result history, run summary, and JSONL logging in Node-RED userDir/logs/slmp-device-matrix-<session>.jsonl
• slmp-routing.json: per-request routing with msg.target
• slmp-udp-read-write.json: basic UDP read/write

Recommended first import:

• start with slmp-basic-read-write.json if you only need to confirm a single PLC over TCP
• use slmp-array-string.json when you want to validate ,count and string handling immediately
• use slmp-device-matrix.json when you need to step through the matrix catalog one by one from the high-level nodes and keep a persistent verification log
• use slmp-control-error.json when you need msg-driven addresses, control messages, or second-output error routing

Known limitations

• Set frame type and PLC series explicitly for each connection
• .bit,count is not supported
• A single client connection keeps requests serialized by default
• Future high-level device support candidates are tracked in the Future Device Support list

Development

Run the local test suite:

cmd /c npm.cmd test

Notes

• .bit notation is only valid for word devices such as D50.3
• Direct bit devices should be addressed directly as M1000, X1F, Y20
• Random read batching follows the Python helper layer for batchable word devices
